Product Description
Small quanity of piezo single crystal PMNPT (TRS X2B) remaining materials from completed projects. Sale for research.
0.5 mm thick, 10 mm x 10 mm size, with Cr+gold electrode
High d33 > 1700 pC/N,
fs ~ 3.7 MHz, fp ~ 4.4 MHz, kt ~0.57, Capacitance (free) ~9.3 nF, DF(free) ~0.36%, Dielectric constant (free) ~ 5526 (23 C), Capacitance (clamped) ~1.37 nF, DF (clamped) ~0.%, Dielectric constant (clamped) ~810, K33 ~ 0.92, speed of sound: ~4650 m/s
