Refurbished Trek 601B-4 [Four channels] High Voltage Amplifier +/-500/10mA Warranty all Cable

Product Description

The Model 601B-4 is a high-voltage amplifier with a 1000-volt output range at 10 mA continuous, 20 mA peak (for 10 μs into capacitive or resistive loads). It uses a floating output driver, allowing the instrument to be strapped to produce an output voltage range of 0 V to +1000 V, 0 V to -1000 V or -500 V to +500 V. As such, the user may select bipolar of full unipolar operation. The four-quadrant output stage sources or sinks current into capacitive or resistive loads anywhere within the output voltage range.

This unit has four independent amplifiers. One Channel does not work. So Only Three channels work.

Output Voltage: 0 to ±500 kV DC or peak AC

Output Current: 0 to ±10 mA continuous or 20 mA peak AC [for 10 us]

Slew Rate: Greater than 50 V/μs

Large Signal Bandwidth: DC to greater than 8 kHz (1% distorsion)

Voltage Gain: 1:100 V/V

Come with two Special High Voltage output cables, two BNC cables, one grounding cable, one power cord, provide up to 1 hour skype training.

Buy with confidence with one month warranty.

Shipping fee is for USA domestic customers. For international customers, we will charge more for UPS Air International shipping with tracking number [you may receive a second invoice for international shipping].

For full datasheet, please visit Trek website:

http://www.trekinc.com/products/601C.asp
