Product Description

Poled PVDF piezoelectric film without electrode. Thickness < 10 um, other thickness available upon request, high d31 >28 pC/N and d33 >10 pC/N.

Typical Thickness: 3-4 um, 4-5 um, 6-7 um, 7-8 um

Sell in size of 150 mm x 150 mm.

Other sizes also available (produced in roll-to-roll with width > 400 mm and length > 100 m)

We can also apply electrode based on request (Vacuum sputtered thin Gold, Aluminum, Silver, Copper, etc).

Note: it is difficult to use d33 meter to accurately measure thin polymer film. The measured value is usually lower than actual performance for thinner film. It is more appropriate to use d31 to characterize thin film <40 um.

For piezo sensors, high frequency ultrasound, loudspeakers.

Also for electroactive polymer EAP actuator, soft actuator, robotics

Uniaxially oriented with high d31 (but almost no d32).

Berkeley and Tsinghua in "Insect-scale fast moving and ultrarobust soft robot", Science Robotics

https://robotics.sciencemag.org/content/4/32/eaax1594

Bending actuator https://www.youtube.com/watch?v=G7-wSv4pUwI

Micro speakers

MIT, Jinchi Han; Jeffrey H. Lang; Vladimir Bulović

A Thin-Film Piezoelectric Speaker Based On An Active Microstructure Array

http://ieeexplore.ieee.org/document/9699609

Microsystems & Nanoengineering volume 8, Article number: 55 (2022)

A versatile acoustically active surface based on piezoelectric  microstructures
