Product Description
Poled PVDF piezoelectric film without electrode. Thickness of 30 um, other thickness available upon request, high d31>30 and d33 >23 pC/N.
Dielectric Constant ~13.0, dielectric dissipation factor ~1.9% at 22 C and 1 kHz
Young's modulus >2.0 GPa at 25 C.
Thermal shrinkage <0.5% at 65 C and 2 hours minutes.
For piezo sensors. loudspeakers, energy harvesting, etc.
Length is 10 m long.
Width: 150 mm or 310 mm.
For prototype piezo sensor development or university research. Will also offer other length at discount.
You may need to use plasma to increase the surface tension to > 50 dynes before applying electrode.
Uniaxially oriented with high d31 (but almost no d32).
The shipping cost is for customers in the USA. For international customers, may need to charge additional air shipping or use customer's shipping account.
If you have issue to pay with credit card, please email us directly sales@piezopvdf.com
