Product Description
Poled PVDF piezoelectric film without electrode. Thickness of 50 um, other thickness available upon request, high d31 >30 pC/N, d33 >23 pC/N.
Dielectric Constant ~13.0, dielectric dissipation factor ~1.9% at 22 C and 1 kHz
Young's modulus >2.0 GPa at 25 C.
Thermal shrinkage <0.5% at 65 C and 2 hours minutes.
For piezo sensors. loudspeakers.
This is a narrow roll of 220 mm wide and 10 m long. For prototype piezo sensor development or university research. Will also offer other length at discount.
You may need to use plasma to increase the surface tension to > 50 dynes before applying electrode.
Uniaxially oriented with high d31 (but almost no d32).
